In product design, the choice of locking gas springs often determines the fundamental difference in user experience. Today, we dive deep into the two main locking types to help you make precise decisions.

Part 1: Rigid Lock Gas Springs – Absolute Stability

Working Principle:
Uses mechanical latches or ratchet mechanisms to achieve complete rigid fixation. When locked, the internal piston stops moving, providing hard support.

Key Features:

• Zero displacement locking: No elastic buffer when locked

• High rigidity support: Withstands impact loads without position change

• Clear feedback: Distinct 'click' sound upon locking

• Relatively complex structure: Requires additional locking mechanism


Optimal Applications:

1. Medical equipment: Surgical beds, dental chairs needing absolute stability

2. Industrial machinery: Fixtures, mold supports requiring precise positioning

3. Vehicle tailgates: Applications needing fixed opening angles

4. Heavy equipment: Tool racks, access doors where safety is priority


Selection Advice:
When your application demands 'rock solid' stability, rigid lock is the only choice. It offers the highest position accuracy but typically at higher cost and weight.

Contact Me

Part 2: Elastic Lock Gas Springs – Flexible Cushioning

Working Principle:
After locking, maintains compressible elastic state, allowing small flexible movements at the locked position.

Key Features:

• Flexible locking: Provides 3-15mm cushioning stroke

• Dynamic adaptability: Absorbs vibration and minor impacts

• Shock protection: Protects equipment and connected structures

• Relatively simple: No complex external locking mechanisms needed


Optimal Applications:

1. Automotive seats: Safety cushioning during collisions

2. Office furniture: Comfortable adjustment of chair backs

3. Outdoor equipment: Accommodates thermal expansion and structural deformation

4. Sports equipment: Fitness machines requiring impact absorption


Selection Advice:
When your application needs both position fixing and impact protection, elastic lock offers the best balance. It sacrifices some rigidity for better safety and comfort.

Part 3: Decision Flowchart – 5 Key Questions

Q1: Is zero displacement required after locking?
Yes → Choose Rigid Lock
No → Next question

Q2: Is there vibration or impact in the environment?
Yes → Lean toward Elastic Lock
No → Lean toward Rigid Lock

Q3: Does the user need clear locking feedback?
Yes → Rigid Lock offers better experience
No → Both acceptable

Q4: Are weight and cost sensitive factors?
Yes → Elastic Lock typically lighter and more economical
No → Decide based on first three questions

Q5: Need to accommodate thermal expansion?
Yes → Elastic Lock is better choice
No → Decide based on first four questions

Part 4: Technical Comparison

Part 5: Common Misconceptions Clarified

Myth 1: 'Elastic lock is just poor-quality rigid lock'
Fact: These are different design philosophies, each with optimal applications.

Myth 2: 'Rigid lock is always safer'
Fact: Under dynamic loads, elastic lock actually provides better safety cushioning.

Myth 3: 'They are interchangeable'
Fact: Wrong choice may damage equipment or create safety hazards. Always use as designed.

Need Professional Selection Advice?
Share your application parameters, and we'll provide tailored technical recommendations.
